Epoxy systems for construction and adhesives applications
Polymers - Performance Materials Business Epoxy resins, reactive diluents and curing agents are manufactured and marketed under the trade name Lapox by the Polymers - Performance Materials Business of Atul. It has received ISO 9001:2008 and ISO 14001 certification and has a NABL accredited laboratory for epoxy testing and analysis. The Company is in this business since 1960. Product range Resins: Bisphenol-A and Bisphenol-F based resins, Modified and formulated resins, Cycloaliphatic resins, Epoxy phenol novolac resins, Multifunctional resins, Benzoxazine resins, Bismaleimide resins, Brominated resins and Dimer acid based resins Curing agents: Aromatic amines and adducts, Aliphatic amines and adducts, Cycloaliphatic amines and adducts, Phenalkamines, Polyamides, Polyamidoamines and Sulfones - 3,3’-Diaminodiphenyl sulfone and 4,4’-Diaminodiphenyl sulfone Reactive diluents: Aliphatic (monofunctional, difunctional and trifunctional), Aromatic (monofunctional and difunctional) and Cycloaliphatic (difunctional) Accelerators, catalysts and flexibilisers Legacy Founded in 1947 by a legendary Indian, Mr Kasturbhai Lalbhai, Atul Ltd (Atul) is the first private sector company of the country to be inaugurated by the first Prime Minister, Pandit Jawaharlal Nehru. About us Atul is one of the largest integrated chemical companies of India with annual revenue of about ` 5,000 cr. The Company manufactures about 900 products (such as para-Cresol and derivatives, resorcinol and derivatives, vat dyes, sulphur dyes, herbicides, fungicides, tissue cultured date palms, active pharma ingredients and intermediates, epoxy resins, reactive diluents, etc) and 400 formulations and owns 140 brands. It serves a wide range of customers belonging to over 30 industries in around 90 countries and has established subsidiary companies in Brazil, China, Ireland, the UAE, the UK and the USA. The Company offers a wide range of products and applications used in Agriculture, Adhesives, Animal Feed, Automobile, Composites, Construction, Cosmetic, Defence, Dyestuff, Electrical and Electronics, Footwear, Food, Fragrance and Flavour, Glass, Home Care, Horticulture, Hospitality, Paint and Coatings, Paper, Personal Care, Pharmaceutical, Rubber, Soap and Detergent, Sport and Leisure, Textile, Tyre and Wind Energy industries. The production facilities of Atul and its associate, joint venture and subsidiary entities are at Ambernath, Ankleshwar, Jodhpur, Panoli, Tarapur and Valsad in India and Somerset in the UK. The first manufacturing site of the Company in Atul, Gujarat is spread over 1,250 acres. The Company has its registered office in Ahmedabad and head office at Atul, both in Gujarat, India. Its shares are listed both at National Stock Exchange and at Bombay Stock Exchange. bird’s eye view of the first site of Atul 3 2
Epoxy primer system act as interface between concrete and screed. Atul offers systems that are VOC-free and have low odour, resulting in improved indoor air quality during application, meeting the highest standards for industrial floor coatings. Features • solvent and phthalate free • high penetration into concrete pores • excellent adhesion to concrete • good adhesion even to wet surfaces • cures at low temperature (upto 5 °C) • offers long working time • ready-to-use • USFDA, 21 CFR 175.300 compliant* • may be applied by brush | roller Applications • natural | kota stones, metal surfaces, old and new concrete Floor coating Primer systems 4 5 Application process Ensure surface is clean, dry and free from foreign contaminants. Fill hollow portions and cracks with mortar mixed with primer system. Mix primer system thoroughly as per the recommended ratio and apply on concrete surface. Allow to cure primer into semi-cure stage. Start application of mortar | screed when primer is slightly tacky. 1 3 2 4 Lapox systems Mixing ratio (resin : curing agent) Mixed1 viscosity @ 25 °C Pot life2 @ 25 °C Colour Recommendations Parts by weight mPa s Minutes Gardner Low viscosity ARB-32 | AH-714 100 : 50 400-600 140-160 Resin: 1 GS Curing agent: 8 GS Very low viscosity system for good wetting of non-porous substrates. B-47 | AH-714 100 : 50 500-700 140-180 Resin: 1 GS Curing agent: 8 GS Low viscosity system for general purpose applications. Medium viscosity ARB-32 | AH-713 100 : 50 3,000-4,000 120-140 Resin: 1 GS Curing agent: 9 GS Flexible system suitable for various substrates. Faster curing can be achieved by adding 3-5% of AC-14. B-47 | AH-713* 100 : 50 3,500-4,500 110-130 Resin: 1 GS Curing agent: 9 GS Recommended for multiple substrates. Faster curing can be achieved by adding 3-5% of AC-14. B-11 | AH-714 100 : 50 7,500-9,500 110-130 Resin: 1 GS Curing agent: 8 GS Suitable for high porosity concrete surface and provides high thickness of coatings. Primer for wet | damp surfaces ARB-32 | AH-747 100 : 60 450-650 50-70 Resin: 1 GS Curing agent: 12 GS Flexible system for application on metal and concrete surface. B-47 | AH-747 100 : 60 500-700 50-70 Resin: 1 GS Curing agent: 12 GS Fast curing system with excellent adhesion to wet | damp surfaces. B-47 | XH-80 100 : 67 1,500-2,500 60-80 Resin: 1 GS Curing agent: 15 GS Low temperature curing system. Cures under high humidity and damp conditions. 1Brookfield viscosity | 2Pot life of 100g mixed mass | Note: B-11 and AR-101 are Bis-A based liquid epoxy resins Technical details
A thick layer of about 3-6 mm of mortar is laid on top of partially cured primer to achieve load bearing properties of flooring. Atul offers a wide range of mortar and screed systems for general purpose and heavy duty floorings. Features • solvent and phthlate free • high compressive strength • very low shrinkage • excellent adhesion to primed surface • excellent stability under static and dynamic load • offers long working time • may be applied by hand trowel | power trowel Applications • anti-skid flooring for parking lots, garages, walk-ways, warehouses and ramps 6 7 Application process Mix resin and curing agent thoroughly in specified ratio. Add quartz sand mix no.10 into resin mixture. Ensure that the primed surface is slightly tacky before application of mortar. Spread uniformly to achieve desired thickness by notch trowel. Level uniformly using hand | power trowel. Allow to cure for minimum 24 hrs to get optimum strength. 4 2 3 HARDNER RESIN 5 1 Floor coating Mortar and screed systems Lapox systems Mixing ratio (resin : curing agent) Mixed1 viscosity @ 25 °C Pot life2 @ 25 °C Colour Recommendations Parts by weight mPa s Minutes Gardner Mechanical strength B-47 | AH-713 100 : 50 3,500-4,500 110-130 Resin: 1 GS Curing agent: 9 GS Standard system for screed lining. B-11 | AH-714 100 : 50 7,500-9,500 110-130 Resin: 1 GS Curing agent: 8 GS System with high mechanical strength for load bearing applications. Chemical resistance ARPN-58 | AH-351 100 : 30 5,000-8,000 25-35 Resin: 3 GS Curing agent: 4 GS Epoxy phenol novolac (EPN) system with excellent chemical resistance to concentrated acids and alkalis. Able to withstand 98% sulphuric acid. ARPN-58 | K-41 | K-42 100 : 65 12,000-16,000 65-85 Resin: 3 GS Curing agent: >18 GS EPN system with excellent chemical resistance to concentrated acids and alkalis. ARPN-58 | K-49 100 : 65 8,000-10,000 100-130 Resin: 3 GS Curing agent: 13 GS Low viscosity EPN system with excellent chemical resistance to concentrated acids and alkalis. Enables higher filler loading. B-47 | K-41 | K-42* 100 : 60 1,000-7,000 150-300 Resin: 1 GS Curing agent: >18 GS Low viscosity system for excellent chemical resistant tank lining and screeds. B-11 | K-41 | K-42* 100 : 60 8,000-15,000 50-140 Resin: 1 GS Curing agent: >18 GS Standard system for excellent chemical resistant tank lining and screeds. B-11 | K-49 100 : 60 7,000-10,000 110-150 Resin: 1 GS Curing agent: 13 GS Standard low viscosity system for good chemical resistant tank lining and screeds. 1Brookfield viscosity | 2Pot life of 100g mixed mass | Note: B-11 and AR-101 are Bis-A based liquid epoxy resins | Use ARPN-59 in place of ARPN-58 for low mixed viscosity | *Combination of two curing agents in specified ratio provides flexibility in working time Technical details
Self leveling systems fromAtul provides high glossy and maintenance-free seamless coating. They offer high mechanical properties and protects the floor from chemical attack. Features • solvent-free • good compatability with additives • aesthetically appealing • scratch and stain resistant • high mechanical properties and good chemical resistance • USFDA, 21 CFR 175.300 compliant* • may be applied by notch trowel | spike roller Applications • operation theaters, pharmaceutical plants, food industry, shopping malls, shopfloors and basement parking 8 9 Application process Mix resin and curing agent thoroughly in the specified ratio. This is called resin premix. Mix silica flour, pigment paste and additive in resin premix. Mix all contents thoroughly with stirrer. Apply uniformly on the floor using notch trowel. 4 2 3 Apply spike roller to remove air bubbles from topcoat. 5 Allow curing for 24 hours to get optimum result. 6 HARDNER RESIN 1 Floor coating Self leveling systems Lapox systems Mixing ratio (resin : curing agent) Mixed1 viscosity @ 25 °C Pot life2 @ 25 °C Colour Recommendations Parts by weight mPa s Minutes Gardner High gloss B-47 | AH-416* 100 : 60 400-600 50-60 Resin: 1 GS Curing agent: 1 GS Standard system for high gloss top coats. Low mixed viscosity offers high filler loading for improved mechanical properties. B-47 | K-302* 100 : 50 400-500 30-40 Resin: 1 GS Curing agent: 2 GS Fast curing system with excellent resistance to amine blush. ARB-22 | AH-416* 100 : 60 600-800 50-60 Resin: 1 GS Curing agent: 1 GS Allows long working time and improved mechanical properties. ARB-22 | AH-428* 100 : 45 300-500 60-70 Resin: 1 GS Curing agent: 1 GS Fast curing system with low mixed viscosity for high filler loading. Specialty ARB-26 | AH-416 100 : 60 400-600 60-70 Resin: Milky white liquid Curing agent: 1 GS Provides good wetting of pigments and facilitates air release during application for excellent surface finish. ARB-26 | K-302 100 : 50 300-500 30-40 Resin: Milky white liquid Curing agent: 2 GS Fast curing systemwith excellent resistance to amine blush. 1Brookfield viscosity | 2Pot life of 100g mixed mass Technical details
Atul provides grouting systems which are an efficient and economical means to install heavy machinery. They offer high compression strength and resistance to vibrations. Features • low viscosity and high filler loading • low exotherm while curing • very low shrinkage • resistant to shock, impact and vibrations • high compressive strength and load bearing property • resistant to oils, fuels and mild chemicals • creates a solid barrier against water penetration Applications • foundation grouts for heavy machines • injection grouts for structural strengthening • tile grouts for decorative purposes 10 11 Application process Clean the concrete surface thoroughly using wire brush | hand tool. Fill surface defects | undulances using epoxy mortar | paste. Mix resin, curing agent and agrregate in specified ratio. Add air release additive before mixing the contents. Pour the epoxy grouting mortar in the specified area. 1 4 2 3 Leave it for a minimum of 24 hours to achieve optimum strength. 5 Grouting systems Lapox systems Mixing ratio (resin : curing agent) Mixed1 viscosity @ 25 °C Pot life2 @ 25 °C Colour Recommendations Parts by weight mPa s Minutes Gardner Foundation grouts B-47 | AH-713 100 : 50 3,500-4,500 110-130 Resin: 1 GS Curing agent: 9 GS Multipurpose system that provides excellent adhesion and high compressive strength. Injection grouts B-47 | AH-714 100 : 50 500-700 140-180 Resin: 1 GS Curing agent: 8 GS Low viscosity system with long working time. ARB-38 | AH-744 100 : 30 300-400 40-60 Resin: 1 GS Curing agent: 8 GS Low viscosity fast reactive system for excellent adhesion with concrete and superior mechanical properties. Tile grouts ARB-22 | AH-714 | AC-14 100 : 50 : 2 600-800 120-150 Resin: 1 GS Curing agent: 8 GS Accelerator: 6 GS Low viscosity system with long working time; provides excellent adhesion to tiles and concrete. 1Brookfield viscosity | 2Pot life of 100g mixed mass Technical details
Atul provides systems with variable pot life, glass transition temperature and curing time. Variable pot life makes it suitable for small to very large jobs. Excellent mechanical properties such as tensile, flexural, shear and compressive strength can be achieved if the epoxy is applied with glass or carbon fiber reinforcement on concrete surfaces. Features • solvent-free • variable viscosities and setting time • high penetration in concerte surfaces • low shrinkage • excellent adhesion to concrete • creates a solid barrier against water penetration • maintains structural integrity and extends life • may be applied by gravity pouring | injection grouting Applications • old structures like bridges, beams, columns, buildings and road cracks Application process Clean the concrete surface thoroughly using wire brush | hand tool. Fill surface defects | undulances using epoxy mortar | paste. Apply epoxy primer on the surface. Mix resin and curing agent. Stir well. 1 4 2 3 Apply fibre on the primed surface when it is slightly tacky. Start application by brush | roller and ensure thorough impregnation of fibre with epoxy system. 5 Leave it for a minimum of 24 hours to achieve optimum strength. 6 12 13 Concrete structure strengthening systems Lapox systems Mixing ratio (resin : curing agent) Mixed1 viscosity @ 25 °C Pot life2 @ 25 °C Colour Recommendations Parts by weight mPa s Minutes Gardner Fast cure ARL-135 | AH-334 100 : 32 700-1,200 25-35 Resin: 2 GS Curing agent: 4 GS Fast curing low viscosity system for quick impregnation of glass and fibres for high mechanical strength. Medium cure ARL-135 | AH-335 100 : 32 500-700 50-60 Resin: 2 GS Curing agent: 4 GS Moderate pot life and low viscosity system with good impregnation capability and mechanical strength. Slow cure ARL-135 | AH-336 100 : 32 500-700 80-100 Resin: 2 GS Curing agent: 4 GS Long pot life and low viscosity system allows adequate working time for large structural repair jobs. 1Brookfield viscosity | 2Pot life of 100g mixed mass | Note: Recommend use of B-47 | AH-713 primer system before application Technical details
Atul offers epoxy systems for injection grouting and crack filling. Add silica flour | sand to achieve thixotropic properties to avoid sagging on vertical surfaces. Features • solvent-free • variable setting time • low viscosity and high penetration • excellent adhesion to concrete • low shrinkage • may be applied by gravity pouring | injection grouting Applications • old structures like bridges, beams, columns, buildings and road cracks 14 15 Application process Clean concrete surface thoroughly using wire brush | hand tool. Widen the crack using V-grooving in case of large cracks. Apply epoxy primer thoroughly into the cracks. Mix resin and curing agent. Stir well. If required, add silica flour | sand. 1 4 2 3 Fill the cracks using spatula | trowel. 5 Allow curing for 24 hours to get optimum results. 6 Repair and crack filling systems Lapox systems Mixing ratio (resin : curing agent) Mixed1 viscosity @ 25 °C Pot life2 @ 25 °C Colour Recommendations Parts by weight mPa s Minutes Gardner Small cracks (<2mm) B-47 | K-48 100 : 18 300-500 25-35 Resin: 1 GS Curing agent: 4 GS Fast cure system for small cracks. B-47 | K-6 100 : 10 300-500 30-40 Resin: 1 GS Curing agent: 3 GS Low viscosity system for micro cracks. Faster reactivity helps quick setting. B-47 | AH-714 100 : 50 500-700 140-180 Resin: 1 GS Curing agent: 8 GS Excellent adhesion and long working time suitable for large repair jobs. Medium cracks (2mm-5mm) B-47 | AH-713 100 : 50 3,500-4,500 110-130 Resin: 1 GS Curing agent: 9 GS Long working time with good adhesion to concrete substrates. Large cracks (>5mm) ARB-28 | AH-714 100 : 50 1,000-1,500 130-150 Resin: 1 GS Curing agent: 8 GS Long working time with good adhesion to concrete substrates. Addition of silica sand gives desired consistency for filling large cracks. 1Brookfield viscosity | 2Pot life of 100g mixed mass Technical details
Atul offers solvent free coating systems for protection against corrosive chemicals on metal and concrete surfaces. They protect floor | substrate from chemicals including acids, alkalis and solvents. Features • solvent-free • very high chemical resistance • USFDA, 21 CFR 175.300 compliant* • may be applied by notch trowel | power trowel, brush and roller Applications • floor coatings in chemical industry, acid resistant linings, tile joints, gap filling in tank farms and glass-filled coating surfaces 16 17 Application process Ensure surface is clean, dry and free from foreign contaminants. 1 Fill surface defects | undulances using epoxy mortar | paste. 2 Apply chemical resistant coat on slightly tacky primed surface. 3 Mix resin and curing agent in specified ratio. This is premix resin. 4 Add quartz sand mix no. 10 into premix resin. 5 Apply chemical resistant mortar using notch trowel. Allow curing for 24 hours. 6 Apply two sealer coats using brush | roller. 7 Allow curing for 24 hours to get optimum results. 8 Chemical resistant systems Technical details Lapox systems Mixing ratio (resin : curing agent) Mixed1 viscosity @ 25 °C Pot life2 @ 25 °C Colour Recommendations Parts by weight mPa s Minutes Gardner Tank lining ARPN-58 | AH-351 100 : 30 5,000-8,000 25-35 Resin: 3 GS Curing agent: 4 GS EPN system for very high chemical resistance to concentrated acids and alkalis. Offers resistance upto 98% sulphuric acid. ARPN-58 | K-41 | K-42# 100 : 65 9,000-10,000 65-85 Resin: 3 GS Curing agent: >18 GS EPN system with excellent chemical resistance to concentrated acids and alkalis.. ARPN-58 | AH-651 | AH-652# 100 : 65 9,000-10,000 65-85 Resin: 3 GS Curing agent: 16 GS EPN system with excellent chemical resistance to concentrated acids and alkalis. ARPN-58 | K-49 100 : 65 9,000-10,000 100-130 Resin: 3 GS Curing agent: 13 GS EPN with low mixed viscosity with excellent chemical resistance. B-11 | K-49 100 : 60 7,000-10,000 110-150 Resin: 1 GS Curing agent: 13 GS Standard low viscosity system for good chemical resistance for screed | mortar, secondary containment and tank linings. B-11 | K-41 | K-42 100 : 60 8,000-15,000 50-140 Resin: 1 GS Curing agent: > 18 GS Standard system for excellent chemical resistant tank lining and screeds. B-47 | K-41 | K-42* 100 : 60 1,000-7,000 150-300 Resin: 1 GS Curing agent: >18 GS Low viscosity system for excellent chemical resistant tank lining and screeds. Secondary containment lining ARB-33 | AH-416 100 : 60 300-500 40-50 Resin: 1 GS Curing agent: 1 GS Low viscosity system with cycloaliphatic amine curing agent for good chemical resistance and high gloss. ARB-33 | K-302 100 : 50 300-500 30-40 Resin: 1 GS Curing agent: 2 GS Fast curing system for high gloss coating with excellent resistance to amine blush. 1Brookfield viscosity | 2Pot life of 100g mixed mass | Note: B-11 and AR-101 are Bis-A based liquid epoxy resins | Use ARPN-59 in place of ARPN-58 for low mixed viscosity | #Combination of two curing agents in specified ratio provides flexibility in working time l tails
Atul offers various speciality systems for water proofing, fibre reinforced plastic (FRP) rebars, clear casting system for table tops and coal tar coating. Features • water proofing - variable pot life and viscosity variants with excellent bonding to concrete surfaces • FRP rebars - light weight, durable, non-corrosive properties with high thermal and excellent mechanical strength • clear casting - exceptionally transparent system for decorative table top applications • coal tar coating - mild to moderate chemical resistance for effluent treatment plant (ETP) and sewerage lines Allied application systems Coal tar Clear casting-table top FRP rebars Water proofing 18 19 Allied application systems Lapox systems Mixing ratio (resin : curing agent) Mixed1 viscosity @ 25 °C Pot life2 @ 25 °C Colour Recommendations Parts by weight mPa s Minutes Gardner Water proofing B-47 | AH-713 100 : 50 3,500-4,500 110-130 Resin: 1 GS Curing agent: 9 GS Multipurpose water proofing system for good adhesion and sealing capability on concrete surfaces. B-47 | AH-714 100 : 50 500-700 140-180 Resin: 1 GS Curing agent: 8 GS Low viscosity water proofing system for good wetting and penetration in concrete and natural stones. B-47 | XH-80 100 : 67 1,500-2,500 60-80 Resin: 1 GS Curing agent: 15 GS Low temperature curing system for curing under high humidity and damp conditions that gives excellent adhesion to metal and concrete substrates. FRP rebars L-12 | K-918 | Accelerator* 100 : 85 600-900 5-12# Resin: 1 GS Curing agent: 2 GS Superior fibre impregnation with excellent thermal and mechanical properties in static and dynamic conditions. Clear casting-table top ARC-44 | AH-384 100 : 30 500-1,000 660-960 Resin: 1 GS Curing agent: 1 GS Long pot life system with low exotherm for glossy transparent casting. Suitable for decorative table top and decoupage applications. Coal tar ARB-28 | K-105 100 : 100 2,500-3,500 20-30 Resin: 1 GS Curing agent: Black Ambient curing system with high reactivity and good chemical resistance to mild acids and alkalis. Suitable for coatings in ETP, drainage pipes and sewerage lines. 1Brookfield viscosity | 2Pot life of 100g mixed mass | Note: *Use accelarator AC-14 | K-13 | AC-18 for different gel-time and Tg requirements | #Gel time at 120 °C with 1% accelerator Technical details l tails
Atul offers epoxy adhesive systems with variable viscosities and pot life to suit a variety of processes and applications. They provide excellent thermal stability, electrical resistance and high mechanical properties alongwith high bond strength. Features • thixotropic and non-sagging • fast curing • excellent adhesion to metal, FRP and ABS substrates • resistant to shock, impact and vibrations • complies to Research Design and Standards Organisation (RDSO) specification for railways* Applications Bonding of - • automotive and general engineering components • fish plates on railway tracks • marble to granite, marble to glass and wood to marble • flexible cable joints and FRP pipes • abrasive flap wheels 20 21 Adhesive systems Lapox systems Mixing ratio (resin : curing agent) Mixed1 viscosity @ 25 °C Pot life2 @ 25 °C Colour Recommendations Parts by weight mPa s Minutes Gardner Multipurpose A-31 | K-31 100 : 80 25,000-40,000 40-80 Resin: off white viscous liquid Curing agent: 8 GS Multipurpose ambient curing system for bonding metal, glass, wood, FRP and natural stones that provides high bond strength and toughness. Ambient cure A-16 | AH-801 100 : 100 10,000-14,000 3-5# Resin: 1 GS Curing agent: 2 GS Rapid cure system that offers 5 minutes cure for bonding multiple subtrates. A-16 | K-6 100 : 10 5,000-8,000 30-40 Resin: 1 GS Curing agent: 3 GS Fast reactive system for natural stone fittings and crack sealing in concrete structures. XR-110 | XH-68 100 : 100 3,000-4,000 25-35 Resin: 5 GS Curing agent: 18 GS Suitable for flexible cable joints. ARA-45 | AH-346 100 : 10 30,000-40,000 25-35 Resin: grey thixotropic paste Curing agent: 8 GS Suitable for bonding abrasive flaps with metal core of small to large grinding wheels. Heat resistant A-38 | K-99 100 : 40 50,000-1,00,000 60-110 Resin: Beige thixotropic paste Curing agent: Off white paste Ambient curing thixotropic system with high temperature resistance upto 120 °C. Suitable for bonding a wide variety of substrates. Hot cure A-16 | K-5 100 : 27 - 170-190 Resin: 1 GS Curing agent: Off white to brown solid System with high temperature endurance upto 165 °C that provides excellent resistance to concentrated acids and alkalis. A-35 | K-35 100 : 30 400-500 > 1 Month Resin: 3 GS Curing agent: 2 GS System with high temperature endurance upto 120 °C that provides excellent bond strength for metals and composite substrates. Recommended for bonding metal inserts in electrical casting applications. Road reflector ARA-19 | AH-725 100 : 50 7,000-9,000 45-55 Resin: 1 GS Curing agent: 8 GS Fast reactive system for bonding road reflectors using silica fillers. Insulated rail joint adhesive A-83 | K-83* 100 : 40 18,000-22,000 60-80 Resin: Off white paste Curing agent: Off white paste Ambient cure high performance system for fabrciation of glued insulated rail joints, approved by RDSO, Indian railways. Structural adhesive ARA-32 | AH-735 100 : 45 Thixotropic paste 120-180 (@ 30°C) Resin: Yellow paste Hardener: Blue paste Thixotropic structural system for FRP, metal, glass and wood substrates, Germanischer Lloyd (GL) approved for wind turbine blades applications. FRP pipe joint adhesive ARA-44 | AH-386 100 : 27 30,000-40,000 20-30 Resin: Off white viscous paste Curing agent: Off white viscous paste Ambient curing thixotropic system with high temperature resistance upto 150°C. Suitable for bonding various metals, FRP and aluminum honeycomb structures. Putty formulations B11 | AH-342 | AH-350 100 : 100 : 10 10,000-20,000 15-25 Resin : 1 GS Curing agent: 8 GS Ambient cure system for putty formulations. 1Brookfield viscosity | 2Pot life of 100g mixed mass | Note: B-11 and AR-101 are Bis-A based liquid epoxy resins Technical details
Atul offers epoxy adhesives for battery lid and terminal sealing including flame retardant (FR) and pigmented systems. They provide very high chemical resistance and excellent adhesion to plastic substrates. Features • solvent-free • fast curing • resistant to strong acids • excellent adhesion to ABS substrates • available in red and black colours • UL94 V0 compliant* Applications • battery lid and terminal sealing 22 23 Application process Fill resin and curing agent in volumetric dosing system. Dispense the material in battery for lid and terminal sealing. Allow to cure battery shell at elevated temperature as per process parameters of production line. 1 3 2 RESIN HARDNER Battery adhesive system 1Brookfield viscosity | 2Pot life of 100g mixed mass Lapox systems Mixing ratio (resin : curing agent) Mixed1 viscosity @ 25 °C Pot life2 @ 25 °C Colour Recommendations Parts by weight mPa s Minutes Gardner Battery lid and terminal sealing - non pigmented system ARB-44 | AH-685 100 : 50 1,500-2,500 8-13 Resin: 1 GS Curing agent: 15 GS Fast reactivity and excellent adhesion to ABS substrates that provides excellent resistance to battery acid. ARA-46 | AH-690* 100 : 50 1,000-1,500 6-13 Resin: 1 GS Curing agent: 15 GS FR system complies to UL-V0 rating with good impact resistance. C-51 | K-6 100 : 10 300-500 30-50 Resin: 1 GS Curing agent: 3 GS General purpose system for small batteries. Battery lid and terminal sealing - pigmented system ARA-47 | AH-696 100 : 50 400-600 25-30 Resin: Red and Black Curing agent: 6 GS Pigmented (red and black) for casting applications in battery terminals. Technical details
Visit us at: www.atul.co.in Disclaimer: Information given in this guide is only for guidance without any responsibility on Atul Ltd (Atul). Results vary depending upon application and various other parameters | conditions for which no guarantee or warranty is given by Atul. Atul will not be liable for any damage | loss which users may suffer. May 2022 KEY MARKETS SOUTH AMERICA Argentina Brazil Colombia Peru AFRICA Algeria Egypt Ethiopia Kenya Morocco Nigeria South Africa Tunisia SOUTH ASIA Bangladesh India Sri Lanka OCEANIA Australia New Zealand SOUTH EAST ASIA Indonesia Malaysia Singapore Thailand Vietnam FAR EAST China, Hong Kong Japan, Korea, Taiwan EUROPE Belgium, Czech Republic, Finland France, Germany, Hungary, Italy Norway, Russia, UK, Ukraine NORTH AMERICA Canada USA MIDDLE EAST Bahrain, Israel, Kuwait Oman, Qatar, Saudi Arabia Turkey, UAE ATUL Aromatics Bulk Chemicals and Intermediates Colors Crop Protection - Bulk Actives Crop Protection - Retail Floras Pharmaceuticals Polymers - Performance Materials Polymers - Retail Atul Europe Ltd Atul House 10, Oak Green Earl Road, Cheadle SK8 6QL United Kingdom (+44 1625) 539209 contact@atuleurope.com INDIA OUTSIDE INDIA Atul Brasil Quimicos Ltda Avenido lpiranga, 318 Conjunto 1.001 Bloco A - Bairro República São Paulo (SP), CEP 01046-010 Brazil (+55 19) 99944-2500 contact@atulbrazil.com Atul China Ltd Room number 806 Building 2E 686 Wuzhong Road Shanghai 201103 China (+86 21) 64753255 contact@atulchina.com Atul USA Inc 6917 Shannon Willow Road, # 400 Charlotte, NC 28226 United States of America (+1 704) 540 8460 contact@atulusa.com Atul Middle East FZ-LLC Office number 43, Floor 3 Nucleotide Complex Dubai Science Park, Emirates Road Al Barsha South, Dubai PO Box 500767 United Arab Emirates contact@atuluae.com Head office Atul 396 020, Gujarat India (+91 2632) 230000 contact@atul.co.in www.atul.co.in www.facebook.com/AtulLtd linkedin.com/company/atul-limited/ Registered office Atul House G I Patel Marg Ahmedabad 380 014, Gujarat India (+91 79) 26461294 shareholders@atul.co.in Mumbai office Atul House 310 B, Veer Savarkar Marg Dadar (West) Mumbai 400 028, Maharashtra India (+91 22) 62559700 Mumbai office Floor 15, C wing, Lotus Corporate Park Western Express Highway Goregaon (East) Mumbai 400 063, Maharashtra India (+91 22) 62505200 polymers@atul.co.in
